R&S offers high speed and rapid roll-up doors by Dynaco, a leader in the high-speed door industry for over 20 years. Dynaco doors are by far the most technically sound, long lasting doors in their field.




M2 DOORS SPEED DOORS (UP TO 18’ WIDE)


M2 BASIC

  • Basic model for up to 100 cycles per day
  • For most interior or exterior applications
  • Operates at 24″ per second
  • Infrared photocell on both sides
  • Soft bottom edge
  • Pneumatic bottom edge detector
  • Curtain made of reinforced PVC vinyl
  • Custom fit to your specific opening
  • Applications of up to 12′ x 12′
  • Extremely affordable
  • Click here for brochure

POWER M2, ALL WEATHER M2

  • For exterior openings with high winds or harsh environments
  • Withstands extreme pressure differentials
  • High wind resistance
  • Maximum standard dimensions up to 39′ x 18′
  • Operating speed from 48″ to 96″/second
  • Gear driven, push pull operation
  • Curtain made of reinforced PVC vinyl
  • Infrared photocell in side guides
  • Soft bottom edge
  • Pneumatic bottom edge detector
  • Up to 110 MPH, depending on door size


STAINLESS STEEL M2

Designed for interior and exterior environments such as agriculture or food, or for similar industries where a high degree of hygiene, frequent cleaning, excellent sealing and/or corrosive conditions are present.

  • Designed for interior or exterior environment where a high degree of hygiene and frequent cleaning are required, and where exceptional sealing is needed or corrosive environments exist.
  • Resists winds up to 95 MPH.
  • Maximum standard dimensions 18′ x 18′.
  • Operating up to 96″/sec.
  • Curtain made of reinforced PVC vinyl.
  • Infrared photocell in side guides.
  • Soft bottom edge.
  • Pneumatic bottom edge detector. Stainless steel doors suit the agricultural, food, hygienically sensitive, wash down areas or where corrosive environments exist.

FREEZER M2

  • Works in temperatures of up to -22 degrees
  • Maximum standard dimensions 15′ x 15′ opening
  • Operating Speed: 96″/sec. open, 48″/sec close
  • Curtain made of reinforced PVC vinyl
  • Heated side guides
  • Berner unit available to minimize condensation and moisture
  • Infrared photocell in side guides
  • Soft bottom edge
  • Pneumatic bottom edge detector
  • Designed for interior or exterior cold storage, freezers, or processing to freezers

CLEAN ROOM M2

Designed for an interior environment type cleanroom class 10,000 to 100,000 (according to Fed/Std 209 E) demanding a limitation of the leak flow at a difference in pressure up to 0.82 lbs/sq ft. (drafts of 19 MPH indicative, not including any multiplication coefficients taking into account the configuration of the building).

  • Designed for cleanroom class operations requiring limitation in leak flow of up to 0.82 lbs per square foot per federal standard 209E.
  • Maximum standard dimensions 18′ x 18′.
  • Curtain made of PVC reinforced vinyl.
  • Operating speed up to 96″/sec.
  • Infrared photocell in side guides.
  • Soft bottom edge.
  • Pneumatic bottom edge detector.
  • Designed for interior contamination control in the pharmaceutical, electronic, hospital, laboratory or other controlled environments.

M3 DOORS SPEED DOORS (OVER 18’ WIDE)


POWER M3

For inside and outside environments

  • Curtain made of reinforced PVC vinyl
  • Infrared photocell in side guides
  • Soft bottom edge
  • Pneumatic bottom edge detector
  • Maximum standard dimension up to 39′ x 18′
  • High wind resistance
  • Operating speeds from 48″ to 96″ per second
  • Gear driven, push pull operation
  • Recommended for high traffic areas

ALL WEATHER M3

For outside environments exposed to high winds and other weather extremes

  • For exterior openings with high winds or harsh environments
  • Withstands extreme pressure differentials
  • High wind resistance
  • Maximum standard dimensions up to 39′ x 18′
  • Operating speed from 48″ to 96″/second
  • Gear driven, push pull operation
  • Curtain made of reinforced PVC vinyl
  • Infrared photocell in side guides
  • Soft bottom edge
  • Pneumatic bottom edge detector
  • Up to 110 MPH, depending on door size
